产品特性  Product features
1.落地空间小，交叉立柱，单级双油缸举升，油缸设置在立柱内，
节省空间
2.平衡阀自动调节平衡，运行平稳
3.自动锁紧和解锁，安全可靠
4.载车平台可选用波浪板或是花纹板
5.金属部分表面喷塑处理，色彩美观，经久耐用
Foldable posts' design to occupy small space.
Single stage dual-cylinder lifting system.
Balance valve to ensure automatic synchronization of both posts.
Automatic lock & electric Lock release
Platform with optional wave or diamond plates.
Steel parts are sandblasted then anti-corrosion primer painted and
top finish color coated

产品参数Produ ict parameters
型号(Model No.) : PSL25/2000
举升重量(Lifting Capacity)  :2000 Kg
总高度(External Height) : 2077 mm
总宽度(Overall Width) : 2450 mm
车道宽度(Drive Through) : 2126 mm
举升高度(Lifting Height) :2000 mm
安全设施(Safety Device) : 安全锁Safety lock
操作方式(Operation Mode)  :自动Automatic
安装空间(Installation Space)   :4500 x 2750 x 2200 mm
上升下降时间(Rise/Drop Time)  :   50S/ 40 S
电源/功率(Power Supply / Motor Capacity)   220V/ 380V，50Hz/ 60Hz, 1 Ph/ 3 Ph, 2.2 Kw
