AA4C 4WD CTDCG-3-4WD vehicle chassis dynamometer machine

  • CTDCG-3-4WD
  • AA4C 4WD CTDCG-3-4WD vehicle chassis dynamometer machine

Description

Load 4t CTDCG-3-4WDA Auto Car Vehicle Test Line for Horse Power Machine Automobile Dynamic and Chassis Dynamometer
Product description:
Horsepower machine is a special equipment for testing the power of automobile chassis, and it is also a kind of chassis dynamometer. It can accurately reflect the dynamic performance of the vehicle at each speed, which is convenient for the adjustment of the vehicle's power; it uses the scientific detection method and the system inertia adaptive algorithm to accurately calculate the output power of the vehicle chassis. It can also detect the maximum speed, acceleration time (performance), etc. The control system adopts high-speed data bus with WiFi interface. The control computer can be PC or laptop, which is convenient for operation. You can know your car’s condition anytime by the routine test and simulated road conditions test. It is very suitable for used car evaluation center, automobile repair shop, automobile refitting, ECU adjustment industry.
Configuration feature:
  1. Test power data: region-wide speed horsepower engine/torque curve can accurately reflect the reaction of arbitrary rotational speed (typically 2000 rpm or more) of the engine operating conditions. The most prominent is the output value of the maximum horsepower and torque.

  2. Simulated road test: the roller of the horsepower machine can be controlled by the computer to set the resistance and simulate various resistance conditions of the road. As long as it is properly adjusted, it is safe to run dozens or even 200kW/h on the horsepower machine.

  3. Diagnosis of automobile power condition: a powerful horsepower machine with a clock diagnosis method. If the constant speed function is used, the horsepower engine can use the constant speed function. The horsepower engine can limit the car to a desired speed (a reasonable speed). At this time, the speed (RPM) in the same gear is unchanged. Changing the throttle opening and closing degree or ECU working parameters can get different horsepower output. It is better to cooperate with the knock receiver, air-fuel ratio meter, air flowmeter, etc., which may better judge the work status of the car immediately.

Technical Parameter:

Item CTDCG-3-4WDA CTDCG-3-4WD
Rated Axle Load 10000 kg 10000 kg
Max. testing axle load 3500 Kg 3500 Kg
Testing house power 1000ph 2000ph
Max. traction ≥ 2 5 ≥ 2 5X2
Roller diameter × length Φ216×850mm Φ216×850mm
Inner distance of roller × outer distance 700×2400mm 700×2400mm
Distance between roller centers 437 mm 437 mm
Max. test speed ≥ 20km/h ≥ 20km/h
The Test range of wheelbase / 2100-3200 mm
Wheelbase adjustment range / 0-1100 mm
≤ ±1% ≤ ±1% ≤ ±1%
≤ ±2% ≤ ±2% ≤ ±2%
Gas source ≥0.8Mpa ≥0.8Mpa
Reference inertia 908kg ±18kg 908kg ±18kg
Power absorption device Air cooled eddy current machine Air cooled eddy current machine
Rated Absorbed Torque 3200 N.m 3200 N.m
