AA4C high-quality air water cooling silent diesel generator diesel genset 10kva EF10500STE

  • EF10500STE
  • AA4C high-quality air water cooling silent diesel generator diesel genset 10kva EF10500STE

Description

AA4C high-quality air water cooling silent diesel generator diesel genset 9kva EF10500STE


Model EF10500STE
Rated Frequency[Hz] 50
Rated Voltage[V] 220V60hz,1ph
Rated Output Power[Kva] 9kva
Max Output Power[Kva] 10kva
DC Output 12V 8.3A
Phase Number Single Phase
Excitation Mode Self-excitation , brush
Power FactorΦ 1.0
Insulation Grade F
Fuel Tank Capacity[L] 25
Engine Model 195FD
Starting System Electric Starting
Engine Type 1-Cylinder ,4-Stroke, Air-cooled,Veritical
Broke * Stroke[mm] 95*75
Displacement 0.531L
Compression Ratio 20:1
Rated Rotation Speed[rpm] 3600
Rated Power[Kw] 11.5
Lube[L] 1.8
Fuel Type 0#(summer), -10#(winter), diesel oil
Lube SAE10W30 ( above CD grade )
Low Oil Pressure Alarm System With
Overall Diemension [mm]( L*W*H) 970*560*730
Net Weight[Kg] 170KG



experience unrivalled silence and reliability with our air cooling silent diesel generator

noisy generators can be frustrating, especially when you have sensitive neighbors that your activities could disrupt. luckily, our air cooling silent diesel generator is a perfect fit for those who want to work or enjoy their leisure activities in peace.

our silent diesel generator features cutting-edge air cooling innovation that keeps noise levels low while powering up to meet your energy needs reliably. you no longer have to worry about compromising on the quality of performance as you will experience outstanding fuel efficiency, high uptime, and low maintenance with our product.


features:

our air cooling silent diesel generator boasts impressive features that set it apart. they include:

- low noise levels: at an average sound output of just 65 decibels, our generator delivers power without disrupting your peace.
- efficient fuel consumption: with its advanced engine technology, our generator uses much less fuel than many other diesel-powered generators.
- enhanced reliability: the generator's air cooling feature eliminates the need for frequent repairs or the replacement of water pumps and radiators usually found in liquid-cooled models,
- durable construction: our generator's tough exterior fittings and rugged design ensure it withstands extreme weather conditions, thus giving you uninterrupted power even in harsh environments.
- safety standards: our generator meets all necessary safety standards and regulations making it a safe power solution for both indoor and outdoor use.


applications:

our air cooling silent diesel generator is ideal for various critical applications such as;

- residential backup power
- commercial backup power
- hospitals and healthcare facilities
- data centers and it servers
- manufacturing industries
- construction sites
- remote mining locations
- disaster management operations


conclusion

get yourself the best value for money with our exceptional air cooling silent diesel generator. whether you need reliable backup power at home or require uninterrupted power in industrial settings, we've got you covered. don't compromise on quality or suffer the inconvenience of noisy generators anymore. choose our generator, and enjoy unrivaled silence, reliability, and performance all in one package!





air cooling and water cooling are two methods of dissipating heat from a diesel generator's engine. the main differences between them are:


1. cooling medium: in air cooling, the engine is cooled by air flowing over it, while in water cooling, the engine is cooled by circulating water.


2. efficiency: water cooling is generally more efficient than air cooling because water has a higher specific heat capacity than air. this means that water can absorb more heat per unit of volume than air, which results in better cooling performance.


3. maintenance: air cooling systems are typically less complex than water cooling systems, which makes them easier to maintain. however, they require more frequent cleaning to prevent buildup of dirt and debris, which can reduce their cooling effectiveness.


4. noise: air cooling systems tend to be noisier than water cooling systems because the fans used to circulate the air can be quite loud. water cooling systems are usually quieter because the water pump operates at a lower frequency than air fans.

in summary, air cooling is simpler and cheaper to install but may require more maintenance. water cooling is more effective at dissipating heat and tends to be quieter, but requires a more complex system and higher initial costs. ultimately, the choice of cooling method depends on factors such as cost, efficiency, and maintenance requirements.
