AA-4P40WA 4 post alignment lift 4.0T   4.3M runway

◆Suitable used in the car 4S shop and the repair and maintain service workshop as vehicles lifting, may also cooperating used with wheel alignment;
◆manual mechine lock release, easy to be operated,and provide electric release for choose;
◆Aluminum shell motor prevents overheated;
+Hydraulic cylinder located inside of runway, perfectly protected;
◆The heavy duty steel wire drum, ensures the vehicles safety;
◆Adjustable runways make lift suitable for more versatile vehicles;
◆The automatic operated mechanical lock engaged in process to ensure the vehicles
lifting safety;
Runway synchronizer system provided for preventing vehicles from tilt possibly;
◆The hydraulic system is equipped with device for over-load prevention;
◆Pipe broken and steel rope broken protection device provided;
◆Routine testing with 115% dynamic and 150% static loading;
◆CE approved.

技术参数TECHNICAL SPECIFICATION:

举升重量/Lifting capacity:4000/4500/5000kg
二次举升重量/Jack capacity: 2500kg
举升高度/Lifting height:1800mm
总高度/Overall height:2000mm
跑道长度/Runway length:4300/4500/4800mm
举升时间/Lifting time:60s
额定油压/Rated oil pressure:18Mpa
电机功率/Motor power:2.2/2.2/3.0 kw
电源要求/Power supply:220V, 240V, 380V, 415V
重量Weight:1100/1200/1300 kg
包装尺寸/Packing size:4400/4600/5100 *500*850mm

Overall size:
