Brake lathe C9350

ITEM NO.: C9350
DESC: Brake lathe C9350
Packed Size:
Color:
Voltage:
Quantity:

Description

C9350 Brake lathe

Feature

1. Quickly，accurately and efficiently to cutting rotor fast and slow setting allow cutting rotor
2. Quickly, accurately and efficiently to cutting drum,Finitely adjustably setting allow cutting drum
3. Three kinds of speed to choice for spindle speed
4. A convenient design allows to quickly change from rotor to drum
5. Position of stop make the lathe stop automatic after the cutting
6. Fully equipped adapter package

Specification

Spindle Travel	6-7/8" / 175mm
Spindle Speed	70，80， 118 RPM
Spindle Feed Speed	Min 0.002 Inch Per Revolution / 0.05 Mm/Rev Max 0.02 Inch Per Revolution / 0.5 Mn/Rev
Cross Feed Speed	Min 0.002 Inch Per Revolution / 0.05 Mn/Rev Max 0.01 Inch Per Revolution / 0.025 Mn/Rev
Handwheel Graduations	0.002" / 0.05mm
Rotor Diameter	7" / 180mm - 15" / 381mm
Rotor Thickness	1-7/8" / 48mm
Drum Diameter	6" / 152mm - 28: / 711mm
Drum Depth	6-7/8" / 175mm
Motor	1PH 220VAC 50/60Hz 3PH 380VAC 50/60Hz
Gross Weight	200KG
Dimension	970X920X1140mm
