MQY-201 Diesel Smoke Meter /Opacimeter

  • MQY-201
  • MQY-201 Diesel Smoke Meter /Opacimeter

Description

MQY-201 Diesel Smoke Meter /Opacimeter



Separated measure unit and control unit for easy operation.

● Advanced divided flow technology, constant temperature control in the testing room.

Large LCD screen with reading of opacity and light absorption coefficient.

Fast warm up, automatic zero and calibration check.

With functions of free acceleration test and dynamic measurement.

RPM and oil temperature measurement.

RS-232 interface.

Optional Micro printer and RPM meter.

Suitable for free Accelerate & LUGDOWN emission test.



technical parameter


  • Technical Data
    Item Resolution Measurement Range Absolute Accuracy
    Opacity (N) 0.01% 0~99.90%

    ±2.0%

    Optical Absorption Coefficient(K)

    0.01 m-1

    (0~16.08) m-1 0.05 m-1
    RPM 1 r/min (300~6000) r/min ±50r/min
    Oil Temperature 1 ℃ (0~200) ℃ ±5℃
    Gas Temperature 1 ℃ (0~150) ℃ ±5℃

    Warm-up time
    less than 15 min
    Power supply AC 220V±22V,50Hz±1Hz, 150W
    Efficient length of Optical Path 215 mm
    Net weight 5 kg(Control unit),  6 kg(Measure unit)
    Dimension(W×H×D) Control unit :353×210×248 mm,
    Measure unit: 525×332×170 mm
    Package Dimension 630×490×432 (mm)
