Specification:

■ Nitrogen Purge(N2P)

■ Inflate up to 6 tires simultaneous

■ Rechargeable Battery

■ 174PSI/12bar/1200kPa

Technical Data Summary

Dimensions(Height*Width*Depth) 1400mm*500mm*600mm

55.1"*19.7"*23.6"

Net Weight                      26.7kg/58.7lbs

Gross Weight                    38kg/83.8lbs

Packing Size(height*Width*Depth)310mm*1420mm*510mm

                                 12.2"*55.9"*20.1"

Power Requirement              24Vdc(2 pcs 12Vdc internal batteries included)

100-240Vac 50 /60HZ charger included

Power Consumption              23VA

Operating Temperature Range    -20℃/-4°Fto70℃/158°F

MaxInletAir/Nitrogen Supply    174PSI /12bar / 1200kPa

Operating Range                 5-174PSI/0.3-12bar/35-1200kPa

OverPressureSettingRange      0-29PSI/0-2.0bar/0-200kPa

Nitrogen Purges                  0-9

Accuracy                        ±1PSI/0.07bar/7kPa

Resolution                       1PSI/0.1bar/5kPa

Units of Measurement            PSI/bar/kPa

Specifications:

1. Adjustable over pressure setting(OPS)

2. Nitrogen purge and fill cycle (N2P)

3. Adjustable number of cycles

4. Adjustable lower purge pressure limit

5. Standard inflate to target

6. 6 air outlets allow simultaneous inflation of up to 6 tires

7. Auto-Start inflation

8. Automatic zero drift adjustment

9. Remain at last setting

10. Comprehensive diagnostics and error reporting

11. Audible and visual end of the cycle signal indicators

12. Large backlight LCD display

13. Vandal resistant mechanical switches

14. Suits Standard nitrogen bottle/Direct nitrogen supply from generator/Air compressor

15. 4 Nos.*8M/26ftstandard hoses with single clip-on closed chuck

16. Long life design, up to 2 days of average usage before recharge
