Middle rise scissor lift

Features:

1. Ideal choice for quick tire replacement and simple device alongside of vehicle
2. Surface mounted or movable used,with optional movable kits
3. Special and practical platform extension design broadens your servie scope
4. ELectrical  release system decreases noise emitted during service work
5. Contifiguring mechanical safety lock to ensure that lift at different heights to get the absolute security
6. Optional 24v safety control system
7. Antiskid platform,aluminium motor prevents overheat
8. Platforms extension for lifting long vehicles
9. 115% dynamic and 150% static loadng test passed
10. CE approved

lifting capacity

3000 kg /6600 lbs

Max Lifting height

1000 mm

Min. height

110 mm

Overall length for platform

1400 mm

Overall width for platform

1760 mm

width between platform

700 mm

Lifting time

30 s

Motor power

2.2 kw

Power supply

220V/380V/415V

Air pressure

6~8 Bar

Weight

500 kg

Packing size

1800x1540x220 (mm)

520x450x1150 (mm)
